Serial No. / Fleet No. 2345 (18773)
Hour meter: 4,708 hours (evolving)
Year: 2015
Engine: Diesel JOHN DEERE 4045 HF – 86 kW at 2,200 rpm
Rotary head: R750.2
● Torque: 750 / 280 / 80 daNm
● Speed: 40 / 120 / 410 rpm (3 speeds)
● Output thread: 3’’ 1/2 REG FE
Useful stroke:
● 900 – 1,200 – 1,500 – 2,200 mm
● Extensions: 300 / 1,200 mm
● Thrust force: 3,000 daN – Pullback force: 3,000 daN

Drilling cage included
Dimensions
● Minimum height out of hole (without extension, without winch): 2,290 mm
● Transport length: 4,140 mm
● Working length: 3,815 mm – Powerpack length: 3,550 mm
● Drill width (without cage): 900 / 1,150 mm – Powerpack width: 1,560 mm
● Weight: 7 tonnes (Drill: 4.8 tonnes / Powerpack: 2.2 tonnes)
● Hose length between drill and powerpack: 20 m
